G Model G125
● Tri.Lobe ● High Efficiency ● Energy Saving
● Low Noise ● Stable Air Flow
● Sturdy Construction ● Easy Maintenance
● Extremely Low Vibration ● Long Lifetime ● Cleaning Air
● No Oily Odors
Model:G Model G125
Use:Waste Water Treatment, Aquaculture, Electroplating Industry, Powder Conveyance, Grain Transport, Paper Making Industry, Food Industry, Semiconductor Industry, Chemical Industry, As Vacuum Dryer, As Vacuum Packing for Food, As Dust Collection Machine…. etc.
Silence Type: Especially suitable to install in Hospital, Hotel, School, esidential Area, Office Building … etc where is prohibited noise.















G125 Performance Curve













G125 Noise curve















G125 Performance Table

RPM 1000 mmAq 2000 mmAq
m3/min kW m3/min kW
750 11.86 3.02 11.3 5.85
900 14.17 3.55 13.56 6.88
1050 16.54 4.08 15.9 7.91
1200 18.97 4.61 18.33 8.94
1350 21.48 5.14 20.85 9.97
1500 24.06 5.68 23.47 11.01
1650 26.71 6.21 26.18 12.04

RPM 3000 mmAq 4000 mmAq
m3/min kW m3/min kW
750 10.76 8.19 10.25 10.63
900 12.97 9.64 12.41 12.5
1050 15.29 11.08 14.7 14.38
1200 17.71 12.53 17.11 16.25
1350 20.25 13.97 19.66 18.13
1500 22.9 15.42 22.34 20
1650 25.67 16.86 25.17 21.88

RPM 5000 mmAq 6000 mmAq
m3/min kW m3/min kW
750 9.76 12.42 9.29 14.55
900 11.88 14.62 11.37 17.11
1050 14.13 16.81 13.59 19.68
1200 16.53 19 15.97 22.25
1350 19.08 21.2 18.53 24.82
1500 21.79 23.39 21.26 27.38
1650 24.67 25.58 24.19 29.95

RPM 7000 mmAq 8000 mmAq
m3/min kW m3/min kW
750 8.85 16.58 8.43 17.99
900 10.88 19.5 10.41 21.16
1050 13.07 22.43 12.57 24.34
1200 15.43 25.36 14.91 27.51
1350 17.99 28.28 17.46 30.69
1500 20.74 31.21 20.24 33.86
1650 23.71 34.13 23.25 37.03













G125 Outline Dimensions



No. Item Material
1 gear box  FC250
2 gear box  SCM415
3 bearing  SUJ2
4 bearing case  FC250
5 side cover  FC250
6 oil plug  S45C
7 lmpeller  FC250
8 eye bolt  S45C
9 shaft seal  S45C
10 oil box  FC250
11 oil splash  SS400
12 oil seal case  FC250
13 screw nut  SS400
14 pulley  FC250
15 oil seal case  NBR
16 oil gauge  S45C
17 oil drainer  S45C
18 cylinder  FC250
19 shaft 軸 SCM440
20 oil gauge  S45C
21 oil drainer  S45C
22 oil splash  SS400















G125 Outline Dimension
