G80V Performance Curve
G80V Noise curve
G80V Performance Table
| RPM | -1000mmAq | -2000mmAq | ||
| Qs | La | Qs | La | |
| 850 | 3.34 | 1.14 | 2.91 | 2.17 |
| 1000 | 4.26 | 1.34 | 3.84 | 2.56 |
| 1150 | 5.19 | 1.53 | 4.77 | 2.94 |
| 1300 | 6.12 | 1.74 | 5.70 | 3.32 |
| 1450 | 7.05 | 1.94 | 6.62 | 3.70 |
| 1600 | 7.97 | 2.14 | 7.55 | 4.09 |
| 1750 | 8.90 | 2.33 | 8.48 | 4.48 |
| RPM | -2500mmAq | -3000mmAq | ||
| Qs | La | Qs | La | |
| 850 | 2.68 | 2.66 | 2.33 | 3.13 |
| 1000 | 3.61 | 3.13 | 3.36 | 3.67 |
| 1150 | 4.53 | 3.59 | 4.28 | 4.22 |
| 1300 | 5.46 | 4.07 | 5.21 | 4.78 |
| 1450 | 6.39 | 4.54 | 6.14 | 5.33 |
| 1600 | 7.31 | 5.00 | 7.07 | 5.88 |
| 1750 | 8.24 | 5.47 | 7.99 | 6.42 |
| RPM | -3500mmAq | -4000mmAq | ||
| Qs | La | Qs | La | |
| 850 | 2.16 | 3.57 | 1.88 | 4.00 |
| 1000 | 3.09 | 4.20 | 2.81 | 4.70 |
| 1150 | 4.02 | 4.83 | 3.73 | 5.41 |
| 1300 | 4.94 | 5.46 | 4.67 | 6.11 |
| 1450 | 5.87 | 6.09 | 5.59 | 6.82 |
| 1600 | 6.80 | 6.72 | 6.52 | 7.52 |
| 1750 | 7.73 | 7.35 | 7.45 | 8.23 |
| RPM | -4500mmAq | -5000mmAq | ||
| Qs | La | Qs | La | |
| 850 | 1.59 | 4.41 | 1.27 | 4.80 |
| 1000 | 2.51 | 5.19 | 2.19 | 5.65 |
| 1150 | 3.44 | 5.97 | 3.12 | 6.50 |
| 1300 | 4.37 | 6.74 | 4.05 | 7.35 |
| 1450 | 5.29 | 7.52 | 4.97 | 8.20 |
| 1600 | 6.22 | 8.30 | 5.90 | 9.04 |
| 1750 | 7.15 | 9.07 | 6.83 | 9.90 |
G80V Outline Dimensions
| No. | Item | Material |
| 1 | gear box 齿轮箱 | FC250 |
| 2 | gear box 齿轮 | SCM415 |
| 3 | bearing 轴承 | SUJ2 |
| 4 | bearing case 轴承座 | FC250 |
| 5 | side cover 侧盖 | FC250 |
| 6 | oil plug 加油塞 | S45C |
| 7 | lmpeller 叶轮 | FC250 |
| 8 | eye bolt 吊环 | S45C |
| 9 | shaft seal 轴封 | S45C |
| 10 | oil box 油箱 | FC250 |
| 11 | oil splash 甩油片 | SS400 |
| 12 | oil seal case 油封座 | FC250 |
| 13 | screw nut 螺帽 | SS400 |
| 14 | pulley 皮带轮 | FC250 |
| 15 | oil seal case 油封 | NBR |
| 16 | oil gauge 油镜 | S45C |
| 17 | oil drainer 泄油塞 | S45C |
| 18 | cylinder 汽缸 | FC250 |
| 19 | shaft 轴 | SCM440 |
| 20 | oil gauge 油镜 | S45C |
| 21 | oil drainer 泄油塞 | S45C |
| 22 | oil splash 甩油片 | SS400 |
G80V Outline Dimension
